项   目 (Item) 数   据 (Data)
认证(APPROVAL)  认证查询链接  认证查询链接
测试标准(Test standard) IEC/ EN60998-1：2004 / UL1059
产品间距(Pitch)                                      [mm] 5.08
极数(Poles) 02-XXP
EN60998测试数据（EN60998  Test data) VDE certificate NO. 40022126
额定电压(Rated voltage)                              [V] 250
额定电流(Rated current)                              [A] 15
额定连接容量(Rated connection capacity)(solid/stranded) [mm² ] 0.2~1.5
过压类别/污染等级/绝缘材料组别

(Surge voltage category/pollution degree/material group)

 III/2/I
工频耐压(Withstanding Voltage)                     [KV/min] 2.0
额定扭矩(Rated torque)                               [N.m] 0.5
UL1059测试数据（UL1059Test data) UL File Number E228872
应用组别(Use group) B C D
额定电压(Rated voltage)                              [V] 300 / 300
额定电流(Rated current)                              [A] 12 / 10
额定连接容量(Rated connection capacity) (solid/stranded) [AWG] 26-14
额定扭矩（Rated torque）                            [Lb. in] 4.43
通用数据(General data) /
螺丝(Screw) M3
阻燃等级(Inflammability class)UL94 V-0
环境温度(Ambient temperature)                        [℃] -40~+105
相对湿度(Relative humidity) 5%-95%
抽样检验标准(Inspection standard） MIL-STD-105E II
允收水准(AQL) 0.65
保质期(Warranty) 12 months
材质和电镀(Material and plating) /
绝缘材质(Housing) PA66
螺丝(Screws) Steel，Zn plated钢,镀锌
触点材料(Contact) Copper alloy，Sn plated铜合金，镀锡
方盒(Cage) Copper alloy，Ni plated铜合金，镀镍
接线方法 (Wire connecting)
推荐剥线长度6~7mm; Recommended stripping length 6~7mm;
1.）单股硬导线，剥好对应长度的导线后，用额定的扭力拧紧；

For solid wire, stripping wire to the appointed length, then tightening with rated torque.
2.）多股柔性导线，剥好对应长度的导线后，可以直接连接或者配套使用对应标准规格的冷压端头，用额定的扭力拧紧；

For stranded wire: stripping wire to the appointed length, mating with corresponding type of ferrule, then tightening with rated torque.
注意事项：扭力要平稳，不能使用爆发力；( Tightening process should be steady, can’t use explosive force.)
