| 项 目 (Item) | 数 据 (Data) | ||
| 认证(APPROVAL) | 认证查询链接 | 认证查询链接 | |
| 测试标准(Test standard) | IEC/EN60998-1：2004 / UL1059 | ||
| 产品间距(Pitch) [mm] | 7.5 | ||
| 极数(Poles) | 02-03P | ||
| EN60998测试数据（EN60998 Test data) | 40024856 | ||
| 额定电压(Rated voltage) [V] | 450 | ||
| 额定电流(Rated current) [A] | 18 | ||
| 额定连接容量(Rated connection capacity)(solid/stranded) [mm²] | 0.5-2.5 | ||
| 过压类别/污染等级/绝缘材料组别
(Surge voltage category/pollution degree/material group) |
III/2/I | ||
| 工频耐压(Withstanding Voltage) [KV/min] | 2.5 | ||
| 额定扭矩(Rated torque) [N.m] | 0.34~0.40 | ||
| UL1059测试数据（UL1059Test data) | UL File Number E228872 | ||
| 应用组别(Use group) | B | C | D |
| 额定电压(Rated voltage) [V] | 300 | / | / |
| 额定电流(Rated current) [A] | 10 | / | / |
| 额定连接容量(Rated connection capacity) (solid/stranded) [AWG] | 26~14 | ||
| 额定扭矩（Rated torque） [Lb. in] | 3.01~3.54 | ||
| 通用数据(General data) | / | ||
| 螺丝(Screw) | M2.6 | ||
| 阻燃等级(Inflammability class)UL94 | V-0 | ||
| 环境温度(Ambient temperature) [℃] | -40~+105 | ||
| 相对湿度(Relative humidity) | 5%-95% | ||
| 抽样检验标准(Inspection standard） | MIL-STD-105E II | ||
| 允收水准(AQL) | 0.65 | ||
| 保质期(Warranty) | 12 months | ||
| 材质和电镀(Material and plating) | / | ||
| 绝缘材质(Housing) | PA66 | ||
| 螺丝(Screws) | Steel，Zn plated钢，镀锌 | ||
| 触点材料(Contact) | Copper alloy，Sn Plated铜合金，镀锡 | ||
| 弹片(Wire protector) | Stainless steel不锈钢 | ||
| 接线方法 (Wire connecting) | |||
| 推荐剥线长度5-6mm; Recommended stripping length 5-6mm; | |||
| 1.）单股硬导线，剥好对应长度的导线后，用额定的扭力拧紧；
For solid wire, stripping wire to the appointed length, then tightening with rated torque. |
|||
| 2.）多股柔性导线，剥好对应长度的导线后，可以直接连接或者配套使用对应标准规格的冷压端头，用额定的扭力拧紧；
For stranded wire: stripping wire to the appointed length, mating with corresponding type of ferrule, then tightening with rated torque. |
|||
| 注意事项：扭力要平稳，不能使用爆发力；( Tightening process should be steady, can’t use explosive force.) | |||
