| 项目(Item) | 数据(Data) | ||
| 认证(APPROVAL) | 认证查询链接 | ||
| 测试标准(Test standard) | IEC60998-1 / UL1059 | ||
| 产品间距(Pitch)[mm] | 3.81 | ||
| 极数(Poles) | 2-24P | ||
| IEC60998-1测试数据（IEC60998-1 Test data) | / | ||
| 额定电压(Rated insulation voltage)[V] | 250 | ||
| 额定电流(Rated current) [A] | 10 | ||
| 额定连接容量(Rated connection capacity)(solid/stranded)[mm²] | 0.2-1.0 | ||
| 过压类别/污染等级/绝缘材料组别 (Surge voltage category/pollution degree/material group) |
III/2/I | ||
| 工频耐压(Withstanding Voltage) [KV/min] | 2.0 | ||
| 额定扭矩(Rated torque) [N.m] | 0.20 | ||
| UL1059测试数据（UL1059Test data) | UL File Number E228872 | ||
| 应用组别(Use group) | B | C | D |
| 电压(Voltage) [V] | 300 | / | 300 |
| 电流(Current) [A] | 8 | / | 8 |
| 额定连接容量(Rated connection capacity) (solid/stranded) [AWG] | 28-16 | ||
| 额定扭矩（Rated torque） [Lb. in] | 1.7 | ||
| 通用数据(General data) | / | ||
| 螺丝(Screw) | M2 | ||
| 阻燃等级(Inflammability class)UL94 | V-0 | ||
| 环境温度(Ambient temperature) [℃] | -30~+120 | ||
| 相对湿度(Relative humidity) | 5%-95% | ||
| 抽样检验标准(Inspection standard） | MIL-STD-105E II | ||
| 允收水准(AQL) | 0.65 | ||
| 保质期(Warranty) | 12 months | ||
| 材质和电镀 | / | ||
| 绝缘材质(Housing) | PA66 | ||
| 螺丝(Screws) | Steel，Zn plated钢，镀锌 | ||
| 触点材料(Contact) | Copper alloy ，Sn plated铜合金，镀锡 | ||
| 弹片(Wire protector) | Stainless steel不锈钢 | ||
| 接线方法(Wire connecting) | |||
| 推荐剥线长度4-5mm; Recommended stripping length 4-5mm; | |||
| 1.）单股硬导线，剥好对应长度的导线后，用额定的扭力拧紧； For solid wire, stripping wire to the appointed length, then tightening with rated torque. 2.）多股柔性导线，剥好对应长度的导线后，可以直接连接或者配套使用对应标准规格的冷压端头，用额定的扭力拧紧； For stranded wire: stripping wire to the appointed length, mating with corresponding type of ferrule, then tightening with rated torque. |
|||
| 注意事项：扭力要平稳，不能使用爆发力；( Tightening process should be steady, can’t use explosive force.) | |||
