15EDGRMG-3.81–DEGSON高正端子代理商
| 项 目 (Item) | 数 据 (Data) | ||
| 认证(APPROVAL) | 认证查询连接/认证查询连接 | ||
| 测试标准(Test standard) | IEC/EN61984：2009 / UL1059 | ||
| 产品间距(Pitch) [mm] | 3.81 | ||
| 极数(Poles) | 2-20P | ||
| EN61984测试数据（EN61984 Test data) | VDE certificate NO. 40022408 | ||
| 额定电压(Rated voltage) [V] | 250 | ||
| 额定电流(Rated current) [A] | 7 | ||
| 过压类别/污染等级/绝缘材料组别
(Surge voltage category/pollution degree/material group) |
III/2/I | ||
| 额定冲击电压(Rated impulse voltage) [KV] | 2.5 | ||
| 额定扭矩(Rated torque) [N·m] | / | ||
| UL1059测试数据（UL1059Test data) | UL File Number E228872 | ||
| 应用组别(Use group) | B | C | D |
| 额定电压(Rated voltage) [V] | 300 | / | 300 |
| 额定电流(Rated current) [A] | 8 | / | 8 |
| 阻燃等级(Inflammability class)UL94 | V-0 | ||
| 环境温度(Ambient temperature) [℃] | -40~+105 | ||
| 相对湿度(Relative humidity) | 5%-95% | ||
| 抽样检验标准(Inspection standard） | MIL-STD-105E II | ||
| 允收水准(AQL) | 0.65 | ||
| 保质期(Warranty) | 12 months | ||
| 材质和电镀(Material and plating) | / | ||
| 绝缘材质(Housing) | PA66,UL94V-0 | ||
| 触点材料(Contact) | Copper alloy，Sn plated铜合金，镀锡 | ||
