15EDGKNH-3.5-DEGSON高正端子代理商
| 项 目 (Item) | 数 据 (Data) | ||
| 认证(APPROVAL) | 查询连接Certificate Search Link
证查询连接Certificate Search Link |
||
| 测试标准(Test standard) | EN61984：2009 / UL1059 | ||
| 产品间距(Pitch) [mm] | 3.50 | ||
| 极数(Poles) | 4-48P | ||
| EN61984测试数据（EN61984 Test data) | VDE certificate NO. 40045517 | ||
| 额定电压(Rated voltage) [V] | 250 | ||
| 额定电流(Rated current) [A] | 9.5 | ||
| 额定连接容量(Rated connection capacity)(solid/stranded) [mm2] | 0.2~1.5 | ||
| 过压类别/污染等级/绝缘材料组别
(Surge voltage category/pollution degree/material group) |
III/2/I | ||
| 额定冲击电压(Rated impulse voltage) [KV] | 2.5 | ||
| 额定扭矩(Rated torque) [N·m] | / | ||
| UL1059测试数据（UL1059Test data) | UL File Number E228872 | ||
| 应用组别(Use group) | B | C | D |
| 额定电压(Rated voltage) [V] | 150 | / | / |
| 额定电流(Rated current) [A] | 8 | / | / |
| 额定连接容量(Rated connection capacity) (solid/stranded) [AWG] | 26~16 | ||
| 额定扭矩（Rated torque） [Lb. in] | / | ||
| 通用数据(General data) | / | ||
| 螺丝(Screw) | / | ||
| 阻燃等级(Inflammability class)UL94 | V-0 | ||
| 环境温度(Ambient temperature) [℃] | -40~+105 | ||
| 相对湿度(Relative humidity) | 5%-95% | ||
| 抽样检验标准(Inspection standard） | MIL-STD-105E II | ||
| 允收水准(AQL) | 0.65 | ||
| 保质期(Warranty) | 12 months | ||
| 材质和电镀(Material and plating) | / | ||
| 绝缘材质(Housing) | PA66 | ||
| 弹片( Spring ) | Stainless steel不锈钢 | ||
| 触点材料(Contact) | Copper alloy，Sn plated铜合金，镀锡 | ||
| 接线方法 | |||
| 推荐剥线长度10mm; Recommended stripping length 10mm; | |||
| 1.）单股硬导线，剥好对应长度的导线后，下压按钮同时将单线接入；
For solid wire, stripping wire to the appointed length ，press button and insert the wire. |
|||
| 2.）多股柔性导线，剥好对应长度的导线后，可以直接连接或者配套使用对应标准规格的冷压端
头，下压按钮同时将线接入； For stranded wire, after stripping ,press button and wiring directly or use with standard mated ferrule . |
|||
