项   目 (Item) 数   据 (Data)
认证(APPROVAL)  认证查询连接   |  认证查询连接
测试标准(Test standard) IEC/EN61984：2009 / UL1059
产品间距(Pitch)                                      [mm] 3.5
极数(Poles) 02~12P/02P~13P
EN61984测试数据（EN61984 Test data) VDE certificate NO. 40038730
额定电压(Rated voltage)                              [V] 250
额定电流(Rated current)                              [A] 8
额定连接容量(Rated connection capacity)(solid/stranded) [mm2] /
过压类别/污染等级/绝缘材料组别

(Surge voltage category/pollution degree/material group)

 II/2/III
额定冲击电压(Rated impulse voltage)                   [KV] 2.5
额定扭矩(Rated torque)                               [N·m] /
UL1059测试数据（UL1059Test data) UL File Number E228872
应用组别(Use group) B C D
额定电压(Rated voltage)                              [V] 300 / /
额定电流(Rated current)                              [A] 8 / /
额定连接容量(Rated connection capacity) (solid/stranded) [AWG] /
额定扭矩（Rated torque）                            [Lb. in] /
通用数据(General data) /
螺丝(Screw) /
阻燃等级(Inflammability class)UL94 V-0
环境温度(Ambient temperature)                        [℃] -40~+130
相对湿度(Relative humidity) 5%-95%
抽样检验标准(Inspection standard） MIL-STD-105E II
允收水准(AQL) 0.65
保质期(Warranty) 12 months
材质和电镀(Material and plating) /
绝缘材质(Housing) LCP
触点材料(Contact) Copper alloy，Sn plated铜合金，镀锡
